Industrial Electric Heating Hot Air Circulation Drying Oven

1. What is an electric heating hot air circulation drying oven?

The electric heating hot air circulation drying oven is an efficient and energy-saving industrial drying equipment suitable for drying and curing a variety of materials. The equipment generates heat through electric heating elements, uses axial flow fans for convection heat exchange, transfers heat to the materials, and continuously replenishes fresh air and exhausts humid air to achieve the ideal drying effect.

2. Advantages of IMA-HX series electric heating hot air circulation oven

• The IMA-HX series hot air circulation oven adopts low-noise, high-temperature resistant axial flow fans and automatic temperature control systems. The entire circulation system is fully closed, so most of the hot air circulates in the oven, which increases the thermal efficiency from the traditional 3-7% to the current 35-45%, and the highest thermal efficiency can reach 50%. The IMA-HX hot air circulation design makes the technology advanced, energy-saving, and improves economic benefits.

• The IMA-HX series hot air circulation oven adopts a forced ventilation function, which ensures that the materials are dried evenly through the wind distribution shutters in the box.

• The IMA-HX series hot air circulation oven can adapt to a variety of different drying needs and is suitable for a variety of materials and products.

• The drying chamber and tray of the IMA-HX series hot air circulation oven are made of high-quality stainless steel materials, which are clean and hygienic and meet GMP hygiene standards.

• The IMA-HX series hot air circulation oven is equipped with an automatic temperature control system. Users can easily set the temperature and time to achieve automatic control of temperature and drying time, thereby improving production efficiency and operational convenience.

3. Application fields of IMA-HX series electric heating hot air circulation oven

IMA-HX series electric heating hot air circulation oven is widely used in the heating, curing, drying and dehydration of materials and products in the pharmaceutical, chemical, food, agricultural and sideline products, aquatic products, light industry, heavy industry and other industries. Such as raw materials, crude drugs, Chinese herbal medicines, extracts, powders, granules, granules, water pills, packaging bottles, pigments and dyes, dehydrated vegetables, dried fruits, sausages, plastic resins, electrical components, baking paint, etc.

4. Main parameters of IMA-HX series electric heating hot air circulation oven

☆The heating source is electric heating

☆Using temperature: heating 25-140℃ (customizable temperature)

☆Special requirements can be customized

☆The baking tray size is uniform and interchangeable

☆Baking tray size: 460mm*460mm*45mm

5. Main details of IMA-HX series electric heating hot air circulation oven
